Price : Call Marketing
ENGINE
Type 4-stroke, Parallel Twin
Displacement 649cc
Bore and Stroke 83.0 x 60.0 mm
Cooling Liquid
Compression Ratio 10.6:1
Valve System DOHC, 8 valves
Fuel System Digital fuel injection with two 38 mm Keihin throttle bodies
Ignition Digital
Lubrication Forced lubrication (semi-dry sump)
DRIVETRAIN
Transmission 6-speed, with positive neutral finder
Final Drive Sealed Chain
Primary Reduction Ratio 2.095 (88/42)
Gear Ratio: 1st 2.438 (39/16)
Gear Ratio: 2nd 1.714 (36/21)
Gear Ratio: 3rd 1.333 (32/24)
Gear Ratio: 4th 1.111 (30/27)
Gear Ratio: 5th 0.966 (28/29)
Gear Ratio: 6th 0.852 (23/27)
Final Reduction Ratio 3.067 (46/15)
Clutch Wet multi-disc, manual
FRAME
Type Diamond, high-tensile steel
Wheel Travel: Front 150 mm (5.9 in.)
Tire: Front 120/70-ZR17
Wheel Travel: Rear 145 mm (5.7 in.)
Tire: Rear 160/60-ZR17
Caster (Rake) 25°
Trail 108 mm (4.3 in.)
Steering Angle (Left/Right) 35° / 35°
SUSPENSION
Suspension, Front 41 mm hydraulic telescopic fork with adjustable rebound and preload
Suspension, Rear Single offset laydown shock with adjustable rebound and spring preload
BRAKES
Front: Type Dual 300 mm petal discs
Front: Calipers 2-piston calipers
Rear: Type Single 220 mm petal disc
Rear: Caliper Single-piston caliper
DIMENSIONS
Overall Length 2,125 mm (83.7 in.)
Overall Width 840 mm (33.1 in.)
Overall Height 1,330 mm (52.3 in.)
Wheelbase 1,415 mm (55.7 in.)
Ground Clearance 180 mm (7.1 in.)
Seat Height 845 mm (33.3 in.)
Curb Mass** 206 kg (454 lbs.)
Fuel Capacity 19 litres (4.2 gal.)
Fuel Consumption 4.5 L/100 km (63 MPG)
PERFORMANCE
Maximum Power‡ 47 kW {64 PS} @ 8,000 rpm
Maximum Torque‡ 61 N·m {6.2 kgƒ·m} @ 6,800 rpm
